MotimateMotimate では、xAPI ステートメントをどのようにマッピングするのですか？

更新
スクリーンショット 2025-03-11 at 17.37.47 copy.png



ここでは、MotimateでExperience API（xAPI）を使用する場合のステートメントマッピングの概要を説明します。

motimateでxAPIを使用する場合は、Experience APIの使用 方法を必ずお読みください。

以下のオブジェクトのステートメントマッピングがある：

モチ

"ステートメント"：{
    "actor"：{
      "name"："{employee_number}|{full_name}|{phone_number}|{user_id}",
      "openid"："https://{motispace}.motimateapp.com/user/{useropenid}",
      "objectType"："Agent"
    },
    "verb"：{
      "display"：{
        "en-US"："COMPLETED"
      },
      "id"："http://adlnet.gov/expapi/verbs/completed"
    },
    "object"：{
      "definition"：{
        "type"："http://adlnet.gov/expapi/activities/course",
        "extensions"：{
          "https://xapi.motimateapp.com/extension/chapters_count"： {motichaptercount}
          "https://xapi.motimateapp.com/extension/course_title"："{motititle}"
        }
      },
      "id"："https://{motispace}.motimateapp.com/course/{motiid}",
      "objectType"："Activity"
}.

パッケージ

{
  "stored"："2021-01-28T15:04:30.409Z",
  "active": true,
  "completedForwardingQueue"：[],
  "failedForwardingLog"：[],
  "client"："5cf92eae9e36cb0424cea",
  "lrs_id"："5cf92eae9e36cb04f4ce9",
  "completedQueues"：[],
  "activities"：[
    "https://{motispace}.motimateapp.com/package/322"
  ],
  "hash"："d9754d536c52e9b1ff1a2afb9cb36a06669",
  "agents"：[
    "https://{motispace}.motimateapp.com/user/{user_id}"
  ],
  "statement"：{
    "actor"：{
      "name"："{employee_number}|{full_name}|{phone_number}|{user_id}",
      "openid"："https://{motispace}.motimateapp.com/user/{useropenid}",
      "objectType"："Agent"
    },
    "verb"：{
      "display"：{
        "en-US"："COMPLETED"
      },
      "id"："http://adlnet.gov/expapi/verbs/completed"
    },
    "object"：{
      "definition"：{
        "type"："http://adlnet.gov/expapi/activities/package",
        "extensions"：{
          "https://xapi.motimateapp.com/extension/courses"：{
            "https://xapi.motimateapp.com/extension/section/8507"：{
              "https://xapi.motimateapp.com/extension/course_title"："12"
            },
            "https://xapi.motimateapp.com/extension/section/8960"：{
              "https://xapi.motimateapp.com/extension/course_title"："fdfsdf"
            }.
          }
        }
      },
      "id"："https://{motispace}.motimateapp.com/package/322",
      "objectType"："Activity"
    },
    "timestamp"："2021-01-28T16:04:30+01:00",
    "id"："7b344082-3f01-467c-9ee2-4a317c84adec",
    "stored"："2021-01-28T15:04:30.409Z",
    "authority"：{
      "objectType"："Agent",
      "name"："Reader",
      "mbox"："mailto:services@example.com"
    },
    "version"："1.0.0"
  },
  "hasGeneratedId": false,
  "deadForwardingQueue"：[],
  "voided": false,
  "verbs"：[
    "http://adlnet.gov/expapi/verbs/completed"
  ],
  "processingQueues"：[],
  "person": null,
  "timestamp"："2021-01-28T15:04:30.000Z",
  "relatedActivities"：[
    "https://{motispace}.motimateapp.com/package/322"
  ],
  "relatedAgents"：[
    "https://{motispace}.motimateapp.com/user/691927a1e6cd5e8a39b80b4a01004eda09a9efe7e31780625fa6",
    "mailto:services@example.com"
  ],
  "organization"："5cf90d3a53101009db13a",
  "_id"："6012d27e79f39d5d49fe8",
  "registrations"：[],
  "pendingForwardingQueue"：[
}.

ラーニング・パス

{
  "stored"："2021-01-28T15:11:37.346Z",
  "active": true,
  "completedForwardingQueue"：[],
  "failedForwardingLog"：[],
  "client"："5cf92eae9e36c16f4cea",
  "lrs_id"："5cf92eae9e36c16f4ce9",
  "completedQueues"：[],
  "activities"：[
    "https://{motispace}.motimateapp.com/learning_path/13"
  ],
  "hash"："062d15b97e64515f0462abbae5b49de54ba8d7c2",
  "agents"：[
    "https://{motispace}.motimateapp.com/user/691929f4014911fc67a1e6cd5e8a39b80b4a01004eda09a9efe7e31780625fa6"
  ],
  "statement"：{
    "actor"：{
      "name"："{employee_number}|{full_name}|{phone_number}|{user_id}",
      "openid"："https://{motispace}.motimateapp.com/user/{useropenid}",
      "objectType"："Agent"
    },
    "verb"：{
      "display"：{
        "en-US"："COMPLETED"
      },
      "id"："http://adlnet.gov/expapi/verbs/completed"
    },
    "object"：{
      "definition"：{
        "type"："http://adlnet.gov/expapi/activities/learningpath",
        "extensions"：{
          "https://xapi.motimateapp.com/extension/sections"：{
            "https://xapi.motimateapp.com/extension/section/19"：{
              "https://xapi.motimateapp.com/extension/section_contens"：{
                "https://xapi.motimateapp.com/extension/section_contents/304"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/course",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/4214"：{
                      "https://xapi.motimateapp.com/extension/course_title"："001 a test"
                    }.
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/305"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/course",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/3441"：{
                      "https://xapi.motimateapp.com/extension/course_title"："00moti"
                    }.
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/306"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/package",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/5431"：{
                      "https://xapi.motimateapp.com/extension/course_title"："Training"
                    },
                    "https://xapi.motimateapp.com/extension/section/5513"：{
                      "https://xapi.motimateapp.com/extension/course_title"："イベントブロック6 R"
                    }
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/307"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/package",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/6783"：{
                      "https://xapi.motimateapp.com/extension/course_title"："M1"
                    },
                    "https://xapi.motimateapp.com/extension/section/6784"：{
                      "https://xapi.motimateapp.com/extension/course_title"："M2"
                    }。
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/308"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/course",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/5975"：{
                      "https://xapi.motimateapp.com/extension/course_title"："ABC"
                    }.
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/485"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/course",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/10273"：{
                      "https://xapi.motimateapp.com/extension/course_title"："すべての言語EN"
                    }
                  }
                },
                "https://xapi.motimateapp.com/extension/section_contents/486"：{
                  "https://xapi.motimateapp.com/extension/section_content_type"："http://adlnet.gov/expapi/activities/course",
                  "https://xapi.motimateapp.com/extension/courses"：{
                    "https://xapi.motimateapp.com/extension/section/10267"：{
                      "https://xapi.motimateapp.com/extension/course_title"："VA 01-18"
                    }.
                  }
                }
              }
            }
          }
        }
      },
      "id"："https://{motispace}.motimateapp.com/learning_path/13",
      "objectType"："Activity"
    },
    "timestamp"："2021-01-28T16:11:37+01:00",
    "id"："582acf7f-7ef9-4954-a2d9-24a33f74bb83",
    "stored"："2021-01-28T15:11:37.346Z",
    "authority"：{
      "objectType"："Agent",
      "name"："Reader",
      "mbox"："mailto:services@example.com"
    },
    "version"："1.0.0"
  },
  "hasGeneratedId": false,
  "deadForwardingQueue"：[],
  "voided": false,
  "verbs"：[
    "http://adlnet.gov/expapi/verbs/completed"
  ],
  "processingQueues"：[],
  "person": null,
  "timestamp"："2021-01-28T15:11:37.000Z",
  "relatedActivities"：[
    "https://{motispace}.motimateapp.com/learning_path/123"
  ],
  "relatedAgents"：[
    "https://{motispace}.motimateapp.com/user/691929f4014911fc67a1e6cd5e8a39b80b4a01004eda09a9efe7e31780625fa6",
    "mailto:services@example.com"
  ],
  "organization"："5cf90d3a53101005719db13a",
  "_id"："6012d42979f39d5d497edfeb",
  "registrations"：[],
  "pendingForwardingQueue"：[]
}.
